GIGABYTE Motherboard B650M AORUS ELITE sAM5 B650 4xDDR5 M.2 HDMI DP mATX
Article:
B650M_AORUS_ELITE
Super price
Leave review
In stock
Shipping methods
- Pickup from New Mail
- New Mail Courier
- Pickup from the store
- Other transport services
Payment methods
- Cash upon receipt
- Bank transfer
- Privat 24
- WebMoney
Features
The GIGABYTE B650M AORUS ELITE is engineered to deliver strong performance with its Twin 12+2+1 Digital VRM and support for the latest AMD Ryzen processors. Its advanced cooling solution features full MOSFET heatsinks, a heatpipe, and high-conductivity thermal pads. Dual M.2 slots include one PCIe 5.0 slot for next-generation SSDs. The board provides USB-C connectivity, 2.5GbE networking, DDR5 support, and an integrated I/O shield. EZ-Latch mechanisms allow tool-free installation of graphics cards and M.2 drives.
Technologies
- Twin Digital VRM 12+2+1
- DDR5 with EXPO/XMP support
- PCIe 5.0 M.2 + PCIe 4.0 M.2
- M.2 Thermal Guard
- Smart Fan 6
- 2.5GbE LAN
- USB-C 20Gb/s (front), USB-C 10Gb/s (rear)
- EZ-Latch quick-release mechanisms
- Q-Flash Plus
- Integrated I/O shield
- HDMI 2.1 and DisplayPort 1.4
For whom
- for gamers seeking stable high performance
- for content creators and designers
- for users building a modern performance PC
- for DDR5 overclocking enthusiasts
- for those needing high-speed PCIe 5.0 storage
-
Towards:gaming (overclocking)
-
Form Factor:micro-ATX
-
For processors:AMD
-
Connection type:AM5
-
Processor compatibility:AMD Ryzen 9000/8000/7000
-
Northbridge (chipset):AMD B650
-
UEFI BIOS:Yes
-
Connector type:DDR5
-
Maximum operating frequency MHz:8000
-
The maximum amount of memory GB:256
-
Graphical interface:PCI-E x16 4.0, PCI-E x4 4.0, PCI-E x8 4.0
-
HDMI Output:Yes
-
Sound:7.1, 5.1, 2, 4
-
Connection interface:M.2
-
SATA3 (6 Gb / s):4 ports
-
LAN (RJ-45):100/1000/2500 Mbps
-
Number of LAN-ports:1
-
LAN-Controller Model:Realtek 2.5GbE
-
USB 2.0 pcs:8
-
USB 3.2 Gen 1:7
-
USB 3.2 Gen 2:3
-
USB 3.2 Type-C pcs:2
-
M.2 connector:2
-
BIOS:UEFI
-
Support software RAID:Yes
-
Аudiochip:Realtek®
-
Display Port:Yes
-
Dimensions (HxW):244 x 244
-
DDR5:4 slots
-
Features:iTE I/O Controller Chip, Q-Flash utility, Voltage detection, Temperature detection, Fan speed detection, Fan fail warning, Fan speed control, Q-Flash Plus button, S/PDIF out header, CPU fan header, system fan headers, clear CMOS jumper, reset button, RGB LED strip header, Front Panel Header, TPM Header, Support for Windows 10 64-bit, Support for Windows 11 64-bit, Internet Security, serial port header, Water cooling flow rate detection, LAN bandwidth management software, Addressable LED Header, Утиліта Q-Flash Plus, system fan/water cooling pump header, water cooling CPU fan header
-
Support for XMP:Yes
