Twin Digital VRM Design
To ensure maximum Turbo Boost and overclocking performance of Intel's new generation CPU, GIGABYTE AORUS series motherboard equip the best VRM design ever built with the highest quality components.
Design Ready for PCIe 5.0
PCIe 5.0 Design supports double the bandwidth of PCIe 4.0 and ensures that compatible with cutting-edge GPUs released in the next few years to their full capability.
DDR5 Memory Upgrade
GIGABYTE BIOS offers pre-defined and retrievable profiles for users to get higher performance easily. The profiles are based on a database that is created by checking each memory IC and PMIC vendors to optimize the modules to unleash their full potential. This is a time saving feature to manually configure overclocked DDR5 memory kits.
M.2 Thermal Guard III
M.2 Thermal Guard III constructed with 6X optimized heat dissipation surface to prevent throttling and bottleneck that high-speed/ large capacity of M.2 SSDs may cause, especially under heavy workload.The special design of heatsink grooves in the direction of CPU further enhances the in-chassis air flow and optimizes the heat convection efficiency.
SMART FAN 6
Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool and quiet. Multiple fan headers can support PWM/DC fan and pump, and users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.
High Current Support
Each fan headers support PWM and DC fan and Water Cooling Pump , and up to 24W (12V x 2A) with Over-Current Protection
Precision Control
Multiple temperature/fan speed control points for precise fan curve
Dual Curve Mode
Slope/Stair dual mode for different user scenario
Fan Stop
Fan can stop completely below users' specified temperature point
802.11ax Wi-Fi 6E
The latest Wireless solution 802.11ax Wi-Fi 6E with new dedicated 6GHz band, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections and speeds up to 2.4Gbps. Moreover, Bluetooth 5 provides 4X range over BT 4.2 and with faster transmission.
Personalization
GIGABYTE motherboards bundle several useful and intuitive software to help users to control every aspect of motherboard and provide customizable lighting effect with outstanding aesthetics to fit your unique personality.
Multi-key
A multi-function reset button that can be reconfigured to other function in BIOS for different user scenarios.
EZ-Latch
With GIGABYTE EZ-Latch, you can DIY your PC in no time, quick and easy.
-
Towards:gaming (overclocking)
-
Form Factor:ATX
-
For processors:Intel
-
Connection type:LGA1700
-
Processor compatibility:Intel Core 12th Generation, Intel Core 13th Generation, Intel Core 14th Generation
-
Northbridge (chipset):Z790
-
UEFI BIOS:Yes
-
Connector type:DDR5
-
Maximum operating frequency MHz:7600
-
The maximum amount of memory GB:256
-
Graphical interface:PCI-E x4 3.0, PCI-E x16 5.0, PCI-E x4 4.0
-
HDMI Output:Yes
-
Sound:7.1, 5.1, 2, 4
-
Connection interface:SATA 3, M.2
-
SATA3 (6 Gb / s):6 ports
-
LAN (RJ-45):100/1000/2500 Mbps
-
Number of LAN-ports:1
-
LAN-Controller Model:Realtek®
-
USB 2.0 pcs:8
-
USB 3.2 Gen 1:5
-
USB 3.2 Gen 2:3
-
M.2 connector:4
-
BIOS:UEFI
-
Support software RAID:Yes
-
Аudiochip:Realtek®
-
Display Port:Yes
-
Dimensions (HxW):305 x 244
-
S/P-DIF:Yes
-
DDR5:4 slots
-
Wi-Fi:Yes
-
Bluetooth:Yes
-
Features:iTE I/O Controller Chip, Q-Flash utility, Voltage detection, Temperature detection, Fan speed detection, Fan fail warning, Fan speed control, Q-Flash Plus button, CPU fan header, system fan headers, clear CMOS jumper, reset button, RGB LED strip header, Clear CMOS button, Support for Windows 10 64-bit, Support for Windows 11 64-bit, Internet Security, Smart Backup function, Water cooling flow rate detection, LAN bandwidth management software, Addressable LED Header, Утиліта Q-Flash Plus, Thunderbolt™ add-in card connector, system fan/water cooling pump header, water cooling CPU fan header
