22U W=600mm D=1000mm Free Standing Versatile Cabinet

Features

The GTV series is designed for server environments with high load requirements. The 22U height supports scalable infrastructure planning and equipment expansion.

Glass front doors allow visual monitoring of device status without opening the cabinet. This approach reduces unnecessary access and maintains stable internal conditions.

The design supports clean and organized cable management.

Adjustable mounting rails with unit markings provide flexibility for different equipment depths. The top panel with spacers improves airflow and allows integration of additional modules.

The steel frame with powder coating ensures durability under heavy loads. Load capacity up to 2000 kg supports dense and complex system installations.

Technologies (used)

• Glass double front doors with metal frame
• 3U brush cable entry panels
• Adjustable 19" mounting rails with markings
• Spacer-mounted top panel
• Knock-down frame structure
• Powder coating (RAL 9005)
• Aluzinc mounting profiles

Technical specifications

• Type: rack cabinet
• Form factor: 19"
• Height: 22U
• Series: GTV
• Dimensions: 600×1000 mm
• Maximum load: 2000 kg
• Front doors: glass, double
• Rear doors: steel, shortened
• Side panels: removable with locks
• Protection rating: IP20 (EN 60529)
• Material: steel, glass
• Coating: powder coated
• Color: black (RAL 9005)
• Mounting rails: adjustable, aluzinc
• Cable entry: sealed top and bottom
• Package: frame, doors, side panels, rails, feet

Who it's for

• Data center engineers
• System administrators
• Infrastructure integrators
• Corporate IT departments
• Telecom installations

Conclusion

The MIRSAN GTV 22U cabinet combines structural strength, visibility, and flexible configuration. Suitable for high-density installations requiring organized cable management and controlled access.
