MikroTik Access Point SXTsq 5 ax

Features

The MikroTik SXTsq 5 ax is designed for outdoor wireless links in urban and remote deployments. Its compact enclosure with multiple mounting options is suitable for poles, masts, and rooftop installations.

The model features a modern dual-core ARM IPQ-5010 processor and Wi-Fi 6 connectivity in the 5 GHz band. Support for 802.11a/n/ac/ax standards provides stable wireless performance and data rates up to 1200 Mbps.

The integrated 16 dBi antenna enables long-distance wireless links over several kilometers. The device has been tested for distances up to 3 km in high-interference urban environments, while line-of-sight deployments can exceed 10 km.

RouterOS Level 4 allows the SXTsq 5 ax to operate not only as a CPE device but also as a full access point. This adds flexibility when building wireless infrastructure.

Gigabit Ethernet and Passive PoE support simplify installation and power delivery through a single cable. Passive cooling helps maintain silent operation and reduces moving components.

Technologies (used)

• Wi-Fi 6
• 802.11a/n/ac/ax
• RouterOS v7
• ARM dual-core CPU
• Passive PoE
• Gigabit Ethernet
• Access Point mode
• 16 dBi antenna
• Passive cooling
• IP55 enclosure

Technical specifications

• Model SXTsq 5 ax
• Product code SXTsq-5axD
• Architecture ARM 32bit
• Processor IPQ-5010
• CPU cores 2
• CPU frequency 800 MHz
• RAM 256 MB
• Storage 128 MB NAND
• Operating system RouterOS v7
• RouterOS license level 4
• Wi-Fi standard 802.11a/n/ac/ax
• Wi-Fi band 5 GHz
• Maximum Wi-Fi speed up to 1200 Mbps
• Wireless chains 2
• Antenna gain 16 dBi
• Ethernet 1 × 10/100/1000
• PoE-in Passive PoE
• Input voltage 12–28 V
• Maximum power consumption 6 W
• Protection rating IP55
• Operating temperature -40 °C to +70 °C

Who it's for

• For wireless network operators
• For countryside properties
• For mast and rooftop installations
• For outdoor Wi-Fi links
• For remote locations

Conclusion

The MikroTik SXTsq 5 ax combines Wi-Fi 6 performance, a 16 dBi antenna, and a compact outdoor enclosure for stable long-distance wireless connectivity. Access point functionality, Gigabit Ethernet, and Passive PoE support make it suitable for a wide range of outdoor networking scenarios.
